Specification
- NW10 to 50, NW63 to 250 and NW, ISO, CF Vacuum Components
- Materials : SUS304 / SUS316 / Al
- Other machining products
Ordering Information
|
① |
Type |
|---|---|
|
K |
ISO-K Clamp Flange Components |
|
② |
Item |
|---|---|
|
ADF |
Adaptor Flange ISO-K/ISO-KF |
|
③ |
Size |
|---|---|
|
63D25D |
NW 63 – NW 25 |
|
63D40D |
NW 63 – NW 40 |
|
63D50D |
NW 63 – NW 50 |
|
100D40D |
NW 100 – NW 40 |
|
④ |
Grade |
|---|---|
|
B |
BA Grade (General) |
|
E |
EP Grade |
|
⑤ |
Material |
|---|---|
|
SS |
Stainless steel 304 |
|
⑥ |
Option2 |
|---|---|
|
U |
UCV Cleaning |
Dimension
Reducing Tee
|
NW |
Ordering No. (Basic) |
A |
|---|---|---|
|
63 / 25 |
AVC-KADF63D25DBSS |
50 |
|
63 / 40 |
AVC-KADF63D40DBSS |
40 |
|
63 / 50 |
AVC-KADF63D50DBSS |
45 |
|
100 / 40 |
AVC-KADF100D40DBSS |
40 |
* Stainless steel 304
* BA Grade
